PAIDI T Series Parameter List
Note: 1. (● Standard, ○ Optional, - Not available); 2. The endurance mileage is under the condition of a load of 200kg, a constant speed of 30km, and an external temperature of 20℃. Our company reserves the right to modify the provided parameters, and no further notice will be given in case of any changes.
| MAIN PARAMETER | PIONEER VERSION | KNIGHT VERSION | FLAGSHIP VERSION |
| L*W*H (mm) | 3330×1080×1700 | 3330×1080×1700 | 3330×1080×1700 |
| Wheelbase (mm) | 2200 | 2200 | 2200 |
| Internal size of container (mm) | 1600×1000×440 | 1600×1000×440 | 1600×1000×440 |
| Tyre size | 145/70 R12 | 145/70 R12 | 145/70 R12 |
| Mn ground clearance(full load) (mm) | ≥140 | ≥140 | ≥140 |
| Min turning radius (m) | ≤3.9 | ≤3.9 | ≤3.9 |
| Max speed (km/h） | ≥45 | ≥45 | ≥45 |
| Curb weight without AC (kg) | 525 | 550 | 550 |
| Rated load capacity（kg) | ≥400 | ≥400 | ≥400 |
| Full load capacity（kg) | 1000 | 1025 | 1025 |
| Range (km) | ≥100 | ≥100 | ≥100 |
| MOTOR/BATTERY PARAMETERS |
|
|
|
| Motor type | PMSM | PMSM | PMSM |
| Battery | Lithium iron phosphate | Lithium iron phosphate | Lithium iron phosphate |
| Battery capacity (kWh) | 5.99 | 5.99 | 5.99 |
| Battery heat management | Air cooling | Air cooling | Air cooling |
| INTERIOR |
|
|
|
| Multi-function instrument (7-inch LCD screen) | - | ○ | ● |
| Reversing camera image | - | ○ | ● |
| Reverse radar | ● | ● | ● |
| CONVENIENT AND COMFORTABLE |
|
|
|
| Material of seats | weave● | weave● | weave● |
| 2 Flat seats | ● | ● | ● |
| CONTROL DEVICE |
|
|
|
| EPS electric power steering | ● | ● | ● |
| Vacuum-assisted braking | ● | ● | ● |
| Slope standing function | ● | ● | ● |
| Single warm air | ● | ● | ○ |
| Manual AC (heat, cool) | - | ○ | ○ |
| MULTIMEDIA |
|
|
|
| Bluetooth function (mobile phone connection) | ● | ● | ● |
| USB interface (1*18W) | ● | ● | ● |
| Loudspeaker (1 No.) | ● | ● | ● |
Monitoring platform T-BOX (remote positioning, fencing, anti-theft, interconnection) | ● | ● | ● |
