| MAIN PARAMETER | PIONEER VERSION | KNIGHT VERSION | FLAGSHIP VERSION | SWAP VERSION |
| L*W*H (mm) | 3320×1080×1700 3495×1200×1700(pro) | 3320×1080×1700 3495×1200×1700(pro) | 3320×1080×1700 3495×1200×1700(pro) | 3320×1080×1700 3495×1200×1700(pro) |
| Wheelbase (mm) | 2200 | 2200 | 2200 | 2200 |
| Internal size of container (mm) | 1610×1000×325 1790×1120×325(pro) | 1610×1000×325 1790×1120×325(pro) | 1610×1000×325 1790×1120×325(pro) | 1610×1000×325 1790×1120×325(pro) |
| Tyre size | 145/70 R12 | 145/70 R12 | 145/70 R12 | 145/70 R12 |
| Mn ground clearance(full load) (mm) | ≥140 | ≥140 | ≥140 | ≥140 |
| Min turning radius (m) | ≤3.9 | ≤3.9 | ≤3.9 | ≤3.9 |
| Max speed (km/h） | ≥45 | ≥45 | ≥45 | ≥45 |
| Curb weight without AC (kg) | 490 500(pro) | 500/With AC 520 505/With AC 525(pro) | 500/With AC 520 505/With AC 525(pro) | 470 485(pro) |
| Rated load capacity（kg) | ≥400 | ≥400 | ≥400 | ≥400 |
| Full load capacity（kg) | 965 975(pro) | 975/With AC 1000 980/With AC 1000(pro) | 975/With AC 1000 980/With AC 1000(pro) | 945 960(pro) |
| Range (km) | ≥100 | ≥100 | ≥100 | ≥40 |
| MOTOR/BATTERY PARAMETERS |
|
|
|
|
| Motor type | PMSM | PMSM | PMSM | PMSM |
| Battery | Lithium iron phosphate | Lithium iron phosphate | Lithium iron phosphate | Lithium iron phosphate |
| Battery capacity (kWh) | 5.99 | 5.99 | 5.99 | 2.88 |
| Battery heat management | Air cooling | Air cooling | Air cooling | Air cooling |
| INTERIOR |
|
|
|
|
| Multi-function instrument (7-inch LCD screen) | - | ● | ● | ● |
| Reversing camera image | - | ● | ● | ● |
| Reverse radar | ● | ● | ● | ● |
| CONVENIENT AND COMFORTABLE |
|
|
|
|
| Material of seats | weave● | weave● | weave● | weave● |
| 2 Flat seats | ● | ● | ● | ● |
| CONTROL DEVICE |
|
|
|
|
| EPS electric power steering | ○ | ○ | ● | ● |
| Vacuum-assisted braking | - | ● | ● | ● |
| Slope standing function | ● | ● | ● | ● |
| Single warm air | ● | ○ | ○ | ● |
| Manual AC (heat, cool) | - | ○ | ○ | - |
| MULTIMEDIA |
|
|
|
|
| Bluetooth function (mobile phone connection) | ● | ● | ● | ● |
| USB interface (1*18W) | ● | ● | ● | ● |
| Loudspeaker (1 No.) | ● | ● | ● | ● |
Monitoring platform T-BOX (remote positioning, fencing, anti-theft, interconnection) | ○ | ○ | ○ | ○ |
